Einnovior provides complete PCB design solution to various sector/domains of the electronics industry. We are experienced in designing and detailing of 36 layer boards with high-speed SERDES and over 15,000 components. Miniature PCB design with mixed-signal design which can fit in a small tube. Our team has experience in delivering desired outputs quickly and accurately as per specifications and guidelines.
We have designed complex SOM (System on Module) boards and products using various Processor like Qualcomm Q410 , Q600, Freescale, TI and other major chipsets with miniature size using HDI technology. We provide an efficient design service to our customers while taking into account all the necessary design criteria to ensure a First-Time-Right Product Design Solution. Our extensive knowledge enables the design team to deliver the product on time with cost effective solutions.
Schematic capture & Symbol creation
Symbol & Footprint Library management
Routing & Component Placement
Full Document Package Creation High speed design (LPDDRx, DDRx, THUNDERBOLT, M.2, U.2, SERDES, XAUI, AUX, SATAx, USBx, PCIe, HDMI etc...)
RF and wireless design
Analog & Digital Circuit Design
Experienced in designing MIL grade boards
High-density/high-pin count designs
Advanced PCB technology like BB via, micro vias, laser via, via-in-pad, ultra-fine pitch BGAs 0.4mm, 0.3mm
Power Supply Design for Automotive, Medical & Defense Industry
Gerber Validation
Layer – Single to multilayer , up to 80 layer
About: Board Complexity- 26 Layers, 15520+ pins, 16039+ signals, 3867 components
Board size- 32 inch x 9.5 inch & 3.5mm thickness
About: Board Complexity- 24 Layers, 12700+ pins, 9200+ signals, 2804 components
Board size- 15.2 inch x 8.7 inch & 2.5mm thickness
About: Board Complexity- 12 Layers, 7000+ pins, 5200+ signals, 1401 components
Board size- 4 inch x 5.7 inch & 1.5mm thickness
About: Board Complexity- 8 Layers, 1800+ pins, 1200+ components
Board size- 5.4 inch x 2.5 inch & 1.2mm thickness
About: Board Complexity- 14 Layers,3700+ pins, 700+signals, 1055 components
Board size- 6.5 inch x 4.5 inch & 2.6mm thickness
About: Board Complexity- 12 Layers, 3300+ pins, 2500+ signals, 652 components
Board size- 4.3 inch x 2.5 inch & 2.6mm thickness
About: Board Complexity- 4 Layers, 1000+ pins, 700+ signals, 301 components
Board size- 3.6 inch x 3 inch & 1.6mm thickness
About: Board Complexity- 8 Layers, 1800+ pins, 1300+ signals, 458 components
Board size- 5.4 inch x 2.5 inch & 1.2mm thickness
About: Board Complexity- 8 Layers, 857+ pins, 600+ signals, 251components
Board size- 2.7inch x .8 inch & 0.8mm thickness
